800RPM Bedspreads Shuttle Computerized Automatic Embroidery Machine 94 Iches

800RPM Bedspreads Shuttle Computerized Automatic Embroidery Machine 94 Iches

  • 800RPM Bedspreads Shuttle Computerized Automatic Embroidery Machine 94 Iches
  • 800RPM Bedspreads Shuttle Computerized Automatic Embroidery Machine 94 Iches
  • 800RPM Bedspreads Shuttle Computerized Automatic Embroidery Machine 94 Iches
800RPM Bedspreads Shuttle Computerized Automatic Embroidery Machine 94 Iches
Product Details:
Place of Origin: China
Brand Name: Yuxing
Certification: CE
Model Number: YXS-94-3C
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: plastic film packing
Delivery Time: 16 Days
Payment Terms: T/T, L/C
Supply Ability: 30 SETS/MONTH
Contact Now
Detailed Product Description
Quilting Width: 2450 Mm Dimension(l*w*h): 4500*1500*1700 Mm
Max Sewing Speed: 800 R/MIN Voltage: 380V OR 220V
Power: 6 KW Weight: 4500 KG
Warranty: 12 MONTH After-sales Service Provided: Online Video
High Light:

Bedspreads Multi Thread Embroidery Machine

,

Multi Thread Embroidery Machine

,

800RPM Computerized Automatic Embroidery Machine

94 iches Computerized Bedspreads Shuttle Quilting Machine



Appropriate to:

bedspread, garment, duvet, comforter, quilt, bag, sleeping-bag, nightgown, and house adornment.



Computerized Quilting Machine Function:

  1. Adopt the advanced computer and mechanistic technology.
  2. Machine's needle bar running with needle bar frame,no need to add extra lube, avoid the materials be soiled by lube.
  3. Adjust speed by computer, the speed can reach 800r/min,the stitch can be set between 2-6mm.
  4. 360°random quilting and limitless multi-span and independent quilting.
  5. Compensation function can effective solution for looping pattern with thick material.
  6. Advanced and practical testing upper thread broken techniques,the machine will be auto-stop when the upper thread is broken.
  7. The infrared system ,make your operate more safe.
  8. The pattern editing is easy to learn.
  9. Machine have ringing notice when start machine.
  10. Needle bar frame structure is more firm and durable, the cost of maintenance is cheaper.
  11. Saddling rack and roller are driven by servo equipment.
  12. The Principal axis uses the frequency conversion device.



Model YXS-94-2/3C
Dimension(L×W×H) 4500*1500*1700
Quantity of needle bar 3
Quilting width 2450
Space between needle rows 152.4(3'+3')
Space between needles 25.4
X-axis movement dispacent 304
Thickness of quilting ≤50
Stitch length 2~6 mm
Speed of operation(m/H) 20~195
Model of needle 16#,19#
Speed of main shaft 800 r/min
Total power required 5.8 KW
Voltage

380V/220V

Gross weight 4500kg





Pattern
