Multi Needle 1400RPM High End Computerized Quilting Machine

Multi Needle 1400RPM High End Computerized Quilting Machine

Multi Needle 1400RPM High End Computerized Quilting Machine
Multi Needle 1400RPM High End Computerized Quilting Machine
Multi Needle 1400RPM High End Computerized Quilting Machine
Product Details:
Place of Origin: China
Brand Name: Yuxing
Certification: CE IOS9001
Model Number: YXS-64-2/3DS
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: export packing
Delivery Time: 15 days
Payment Terms: T/T, L/C
Supply Ability: 20 Sets/month
Contact Now
Detailed Product Description
Max Sewing Thickness: 5 CM Quilting Width: 170 CM
X-axis Movement: 25.4 CM Stitch: 0.2-0.8 CM
Rolling Speed: 500-1400 RPM Voltage: 380V /220V
Condition: New Warranty: One Year
High Light:

1.7M Computerised Quilting Machine

,

1400RPM Computerized Quilting Machine

,

280m/h Computerized Quilting Machine

1.7M High-End Computerized Shuttle Garment Making Quilting Machine 1400RPM



Quilting Machines Appropriate to: Garment, hat, bag, sleeping-bag, nightgown, and house adornments.



Specification



Product Name Computer Shuttle(Lock Stitch) Multi-needle Quilting Machine
Model YXS-64-2DS/3DS
Size(L*W*H) 393.5*175*170cm
Weight 5000kg
Quilting width 1.65m
Quilting thickness ≤50mm
Rolling speed 500-1400r/min
Output 10-260m/hour
Needle type #16,#19, #14
X-axis movement 20.4cm
Needle space 2.54cm
Needle bar space 2row 7.62cm (3" )/3 row15.24cm(3''+3'')
Stitch 0.2-0.8cm
Rated voltage(AC) 380V/50HZ 220V/60HZ
Power 5KW



Function:

· Computer system inset pattern and follow to work

· Convenient pattern editing function

· Ringing notice when start machine

· Auto lift needle and orientation brake system

· 360 random quilting and limitless multi-span and independent pattern quilting un-limited.

· The infrared system make your operate more safe

· Adopt the advanced computer and mechanistic technology

· Saddling rack and roller are drived by servo equipment

· Principal axis uses the frequency conversion device

· Auto stop system when the upper thread is broken.

· Compensation function ,an effective solution for looping pattern with thick material

· Adjust speed by computer system and the speed can reach 1400r/min,the stitch can be set between 2mm-8mm

Multi Needle 1400RPM High End Computerized Quilting Machine 0

Layout of machine

Multi Needle 1400RPM High End Computerized Quilting Machine 1

Pattern:

Multi Needle 1400RPM High End Computerized Quilting Machine 2
