7.5 KW Computerized Chain Stitch Foam Mattress Making Machine

7.5 KW Computerized Chain Stitch Foam Mattress Making Machine

  • 7.5 KW Computerized Chain Stitch Foam Mattress Making Machine
  • 7.5 KW Computerized Chain Stitch Foam Mattress Making Machine
7.5 KW Computerized Chain Stitch Foam Mattress Making Machine
Product Details:
Place of Origin: China
Brand Name: Yuxing
Certification: CE
Model Number: YXN-94-3C
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Export packing
Delivery Time: 15 Days
Payment Terms: T/T, L/C
Supply Ability: 20 SETS/MONTH
Contact Now
Detailed Product Description
Machine Size: 500*160*200 CM Quilting Width: 240 CM
Max Rolling Speed: 900 RPM Weight: 5000 KG
Warranty: One Year After-sales: Online Video Support
Output: 10-200 M/H Stitch: 2-8 MM
High Light:

7.5 KW Mattress Making Machine

,

Computerized Mattress Making Machine

,

240cm Mattress Making Machine

7.5 KW Computerized Chain Stitch Foam Mattress Making Quilting Machine



Quilting Machines Function:

  1. With much more output comparing with Single Needle Quilting Machines .
  2. Adopting Chain stitch quilting mechanism, avoiding frequently replacing bottom thread, and making the quilting stitches much firmer.
  3. Needle bar and press plate are controlled by a double- swinging device without cam avoiding lubrication and dirtying of material
  4. Automatic stop motion control in case the top thread or the bottom thread breaks,automatic needle-lifting and CNC speed adjustment
  5. CE Certificate
  6. Computer precision control system, no need to adjust the press plate's position when the thickness of quilting material varies
  7. Strong functions of pattern-combining and Tack & Jump quilting to enable you to quilt different patterns in same row of the mattresses
  8. Fault detection function for ease of determining the running state of the machine at any given time

Specification:

Product Name Computer Non-shuttle (chain stitch) Multi-needle Quilting Machine
Model

YXN-94-3C(2"+3")

Size(L*W*H) 500*160*200cm
Weight 5000kg
Quilting width 240cm
Needle bar space 50.8,76.2,(2"+3")
Quilting thickness 80mm
Rolling speed 600-900r/min
Output 10-180m/hour
Needle type #21-#24
X-axis movement 41cm
Needle space 25.4mm
Stitch 2-8mm
Rated voltage(AC) 380V/50HZ,/220V/60HZ
Power 7KW



7.5 KW Computerized Chain Stitch Foam Mattress Making Machine 0

7.5 KW Computerized Chain Stitch Foam Mattress Making Machine 1

7.5 KW Computerized Chain Stitch Foam Mattress Making Machine 2

7.5 KW Computerized Chain Stitch Foam Mattress Making Machine 3
