300 cm Multineedle Quilting Machine With Edge Cutting Device

300 cm Multineedle Quilting Machine With Edge Cutting Device

300 cm Multineedle Quilting Machine With Edge Cutting Device
300 cm Multineedle Quilting Machine With Edge Cutting Device
300 cm Multineedle Quilting Machine With Edge Cutting Device
Product Details:
Place of Origin: China
Brand Name: Yuxing
Certification: CE
Model Number: YXS-118-3D
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Export packing
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 25 SETS/MONTH
Contact Now
Detailed Product Description
Product Name: Quilting Machine With Cutting Quilting Width: 300 Cm
Running Speed: Max 1200R/MIN Max Sewing Thickness: 650gsm
Output: 10-240m/h L*W*H: 5340*1750*1700 MM
High Light:

3000mm Multineedle Quilting Machine

,

1200R/MIN Multineedle Quilting Machine

,

240m/h Multineedle Quilting Machine

Multineedle Quilting Machines With Edge Cutting Device and Cutter Panel

The quilting machine with edge cutting device advantage:

The quilting machine roller can pull fabric tight, so when cutting edge, fabric won't go sides, so it cut more acurrately. and it is suitable to different kind fabric(except the non-glue cotton, this fabric easy to make knife get stuck), when cutting, the cutting place is neat without snagging problem. Besides each knife has one stone near it, you only need to press button, stone will sharpen knife automatically.Application



For multineedle quilting machine



This 300cm width multi needle quilting machine is usually suggested for pajamas, quilt, bed cover, etc.



Feature



1. Computer control system , clear and easy to understand, accessible all function in one screen

2. Multi-span independent pattern

3. New CNC system,advanced machine structure,high precision quilting,dispense with too much parameter adjustment or pattern modification during quilting.

4. Advanced and practical up thread-break detection unit.

5. Material rack separation structure ,can reduce the load of the rack effectively.

6. Fault detecting and indication enabling fast fault correction and return operation.

7. Computerized speed governing , max.1200r/min.

8. Needle bar running with needle bar frame,Oil free, sturdy and durable



Guaranty and Installation:



1. Give extra free spare part when ship with the machine.
2. Offer manual, pattern book, installation video and step by step instruction if meet problems.
3. If need field installation or repairing machine, client should bear tickets, food, hotel and labor cost $100/day.

4. Within a year if part is broken, the supplier can replace part for free. Damage resulting from buyer's wrong operation / actions without supplier's guide / force majeure is not in the scope of the warranty. (note bobbin case, bobbin, needles, lamp is not in the scope of the warranty)



Specification:



Model YXS-118-3D
Dimension(L×W×H) 5340*1750*1700 mm
Quantity of needle bar 3
Quilting width 3000 mm
Space between needle rows 152.4 mm(3'+3')
Space between needles 25.4 m
X-axis movement 254 mm
Thickness of quilting ≤50 mm
Stitch 2~8 mm
Speed of operation(m/H) 20~240
Model of needle 16#,19#
Rolling speed 500~1200
Total power required 7.5KW
Voltage

380V/50HZ

220V/60HZ

Gross weight 6200kg



Designs

300 cm Multineedle Quilting Machine With Edge Cutting Device 0300 cm Multineedle Quilting Machine With Edge Cutting Device 1300 cm Multineedle Quilting Machine With Edge Cutting Device 2



300 cm Multineedle Quilting Machine With Edge Cutting Device 3

300 cm Multineedle Quilting Machine With Edge Cutting Device 4
