Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor

Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor

    • Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor
    • Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor
    • Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor
  • Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor

    Product Details:

    Place of Origin: China
    Brand Name: Yuxing
    Certification: CE
    Model Number: YXS-118-2/3D

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiable
    Packaging Details: Export packing
    Delivery Time: 20 Days
    Payment Terms: T/T, L/C
    Supply Ability: 30 SETS/MONTH
    Contact Now
    Detailed Product Description
    Warranty: One Year Max Sewing Speed: 1200 R/MIN
    Dimension(l*w*h): 393.5*175*170 CM Weight: 6200 KG
    After-sales Service Provided: Online Video Quilting Width: 128 Inches
    Voltage: 380V Number Of Head: Multi Needle
    High Light:

    1200r/min Industrial Quilting Machine

    ,

    300 cm Industrial Quilting Machine

    ,

    7.5 KW Industrial Quilting Machine

    128 Inches Computerized Shuttle Multi-Needle Quilting Machines with Japan motor



    Computerized quilting machine



    Function



    1. Adopt the advanced computer and mechanistic technology.

    2. Needle bar running with needle bar frame,no need to add extra lube, avoid the materials be soiled by lube.

    3. The needle bar frame structure is more firm and durable,so that the cost of maintenance is cheaper.

    4. Saddling rack and roller are driven by servo equipment.

    5. Principal axis uses the frequency conversion device.

    6. Adjust speed by computer system, the speed can reach 1200r/min,the stitch can be set between 2mm-6mm.

    7. 360° random quilting and limitless multi-span and independent quilting.

    8. Compensation function, can be solved for looping pattern with thick material.

    9. Advanced and practical testing upper thread broken techniques,the machine is auto-stop when thread is broken.

    10. The infrared system ,make your operate more safe.

    11. Pattern editing is easy to learn.

    12. Have ringing notice when start machine.



    Model YXS-118-2/3D
    Dimension(L×W×H) 5340*1750*1700
    Quantity of needle bar 3
    Quilting width 300 cm
    Space between needle rows 76.2(3') / 152.4(3'+3')
    Space between needles 25.4
    X-axis movement 254
    Thickness of quilting ≤50
    Stitch 2~8
    Speed of operation(m/H) 20~240
    Model of needle 16#,19#
    Rolling speed 500~1200
    Total power required 7.5KW
    Voltage

    380V/50HZ

    220V/60HZ

    Gross weight 6200kg

    Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor 0

    Appropriate to: comforter, quilts, bag, sleeping-bag, nightgown, and house adornments.



    Pattern show

    Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor 1Multi Needle 7.5 KW Industrial Quilting Machine With Japan Motor 2
