    Product Details:

    Place of Origin: China
    Brand Name: Yuxing
    Certification: CE
    Model Number: YXS-64-2D

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiable
    Packaging Details: Packed by plastic film
    Delivery Time: 15 Days
    Payment Terms: T/T, L/C
    Supply Ability: 30 SETS/MONTH
    Contact Now
    Detailed Product Description
    Needle Space: 0.5 Inch Application: Jackets / Bed Cover /clothing
    Product Name: Straight Line Quilting Machine Size: 3935*1750*1700
    Work Width: 170cm Max Sewing Thickness: 50mm
    Speed: 500-1200rpm Yield: Maximum 240m/hour
    High Light:

    0.5 Inch Straight Line Quilting Machine

    ,

    170cm Straight Line Quilting Machine

    ,

    1200rpm Straight Line Quilting Machine

    0.5 Inch High Speed Multi Needle Straight Line Quilting Machine For Jackets



    Description

    This straight line quilting machine work width 64", the needle distance can reach minimum 0.5 inch. It is commonly used for garments industry, like jacket shell. The speed maximum can reach 1200rpm, if making straight lines, the yield is about 200m/hour. The machine body and foot are reinforced based on the former C series structure. Automatic lubrication system prolongs the machine's life span, and simplify the maintenance procedure.



    Strength

    • Machine fuselage and beam are reinforced. More stably on running.
    • Adjust speed by computer 500r-1200r/min, set different stitch length(2mm-8mm) from computer .
    • New upgraded computer system, compatible with embroidery file format(DST/DSB)
    • Pattern compensation function is an effective solution for looping pattern with thick material.
    • Auto stop sensor detect thread condition, when thread broken, machine automatically stop.
    • 180 degree and 360 degree random quilting patterns, and limited multi span for tack and jump designs.



    Parameter

    Model YXS-64-2D
    L×W×H 3935*1750*1700
    Quantity of needle bar 2
    Quilting width 1700
    Space between needle rows 152.4(3'+3')
    Space between needles 25.4
    X-axis movement dispacent 204
    Maximum thickness of padding 50
    Stitch length 2~8
    Speed of operation(m/H) 10~240
    Type of needle 14#, 16#,19#
    Max sewing speed 500~1200
    Total power  4000W
    Voltage

    380V/50HZ220V/60HZ

    Gross weight 4800kg



    0.5 Inch Multi Needle Straight Line Quilting Machine For Jackets 0

    0.5 Inch Multi Needle Straight Line Quilting Machine For Jackets 1
