| Place of Origin: | China |
| Brand Name: | Yuxing |
| Certification: | CE, ISO9001 |
| Model Number: | YXN-94-3DS |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export packing |
| Delivery Time: | 15 Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 30 SETS/MONTH |
| Product Name: | Mattress Quilting Machine | Machine Size: | 500*165*200 CM |
|---|---|---|---|
| Rolling Speed: | 600-1500 RPM | Quilting Thickness: | 8 CM |
| After-sales Service: | Engineers Available To Service Machinery Overseas | Other Function: | Auto Stop / Tack And Jump / Thread Trimming |
| Moving Style: | Frame Moved | Warranty: | 12 Months For Main Part |
| High Light: | 1500RPM Non Shuttle Quilting Machine,8CM Non Shuttle Quilting Machine,1500RPM Mattress Quilting Machine |
||
1500RPM Rolling Speed Multi Needle Non-Shuttle Quilting Machine With FUJI Driver
The MULTI NEEDLE NON-SHUTTLE QUILTING MACHINE is mainly used for sewing upper fabric with foam / polyester wadding and non-woven fabric together for mattress panel, bed cover, quilt, sleeping bag and other textile decoration products. It included more than 200 models design patterns which including 180° and 360° Tack&Jump pattern. Besides the computer system can creat new patterns and add in new patterns.
Non-shuttle quilting machine Advantages:
Specification:
| Product Name | Computer Non-shuttle Multi-needle Mattress Quilting Machine |
| Model |
YXN-94-3DS (2"+3"/3"+3") |
| Dimension (L*W*H) | 560*160*200CM |
| Gross Weight | 8500kgs |
| Work width | 240CM |
| Needle bar distance | 50.8,76.2,(2"+3")/ 76.2,76.2(3"+3") |
| Sewing thickness | 8CM |
| Main shaft speed | 600-1500 (roll/minute) |
| Output | 10-300 (meter/hour) |
| Suitable Needle Size | #21, #22, #23, #24 |
| X-axis movement | 10 inches |
| Needle space | 25.4MM |
| Stitch | 2MM-8MM adjustable |
| Rated voltage(AC) | 3 phase 380V/50HZ,/220V/60HZ |
| Total Power | 8.5KW |
Design show
